Description
The clamp is also designed to support 1-2 Twisted Pair Drop Cables.
The clamp is rated to support Fiber Drop Cables to a maximum of 400lbs with minimal attenuation and 1-2 Twisted Pair Drop Cable up to 550lbs.
Shell, Wedge and Shim are stamped from 201/304 Stainless Steel. The Tail Wire is formed from deadsoft 430 Stainless Steel.
Elongated clamp provides compression over a greater surface area.
Perforations on the shim compress the support members of the fiber cable without causing attenuation of the fiber.
| Parts No. | Description | Material | Shim Type |
| CWC-ESD | Universal Fiber Drop Clamp | SS201/SS304 | Dimpled |
